Bohler US 8/10


Bohler® US 8 is a center bevel rule that is designed to combine the benefits of a side bevel rule with the convenience of a center bevel rule. This unique profile provides reduced edge crush along with improved stripping. Although this rule has different finishes on each side, the tip is still precisely in the center. This is very important to obtain dimensional accuracy when cutting multiple out designs.

Bohlerstrip US 10 has a shaved execution on one side whereas the opposing side is ground. This smooth side supports reduced edge crush on the finished product. The edge tip is still precisely in the center which is very important to sustain dimensional accuracy when cutting multiple out designs.

Steel rule is sold in coils for auto-benders, (wound clockwise CW or anticlockwise ACW). Also available in dispenser coils and boxed strips.



Catalog Number Description   Qty
56220390 Bohler US 8/10 - 4PT, 10T, CF/US, 0.990", 66"x90°, CNN
56221350 Bohler US 8/10 - 4PT, 10T, CF/US, 1", 66"x90°, CNN
56223250 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.910", 66"x90°, CNN
56233695 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", 50"x90°, Clockwise
56285820 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", 66"x90° CO
56272250 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", 66"x90°, Wound Clockwise CO
56273580 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", 66"x90°, Wound Clockwise
56272820 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", 17-1/2" ID, Straight No Notch, Bevel Out, EZ-Coil Clockwise CO
56272630 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", Straight No Notch, Bevel Out, EZ-Coil ACW CO
56272440 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", Curved Not Notched, 66"x90°
56271680 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", Straight No Notch, 48" CO
56271870 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", 66"x45° CO
56272060 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.970", 66"x90° CO
56274340 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", 17-1/2" ID, Straight No Notch, Bevel Out, EZ-Coil Clockwise CO
56274150 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", Straight No Notch, Bevel Out, EZ-Coil ACW
56273770 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", Curved Not Notched, 66"x90°
56273010 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", Straight No Notch, 36" CO
56273200 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", Straight No Notch, 48"
56273960 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", Straight No Notch, Dispenser Coil CO
56273390 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 0.990", 66"x90°
56275290 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1", Straight No Notch, Bevel Out, EZ-Coil ACW
56275100 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1", Curved Not Notched, 66"x90° CO
56274530 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1", Straight No Notch, 36" CO
56274720 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1", Straight No Notch, 48"
56274910 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1", 66"x90°
56232530 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", 35"x90°, CNN
56275480 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.015", Straight No Notch, 36" CO
56276240 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.023", Straight No Notch, Bevel Out, EZ-Coil ACW
56276050 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.023", Curved Not Notched, 66"x90°
56275670 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.023", Straight No Notch, 48" CO
56275860 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.023", 66"x90°
56276430 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.025", Straight No Notch, 48"
56276810 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.030", Straight No Notch, Bevel Out, EZ-Coil ACW
56276620 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.030", Straight No Notch, 36" CO
56276920 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.030", 66"x90°
56276950 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.050", 66"x90°
56276960 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.050", Straight No Notch, EZ-Coil ACW
56277760 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.250", 21-9/16" ID, Curved CO
56277380 Bohler US 8/10 - 4PT, 8T, CF/US, T36, 1.250", Straight No Notch, EZ-Coil ACW
56277000 Bohler US 8/10 - 4PT, 8T, CF/US, T40, 1.125", 66"x90°
56277100 Bohler US 8/10 - 4PT, 8T, CF/US, 1.125", Straight No Notch, Bevel Out, EZ-Coil ACW
56277194 Bohler US 8/10 - 4PT, 8T, CF/US, 1.250", Straight No Notch, Clockwise CO
56277575 Bohler US 8/10 - 4PT, 8T, CF/US, 1.250", 25" ID, Curved
56277370 Bohler US 8/10 - 4PT, 8T, CF/US, 1.250", Straight No Notch
56277190 Bohler US 8/10 - 4PT, 8T, CF/US, 1.250", Straight No Notch, Dispenser Coil CO
56218480 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.875", 14-1/2" ID, Curved
56218290 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.875", Straight No Notch, 48"
56218860 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.970", Straight No Notch, Bevel Out, EZ-Coil ACW CO
56219240 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.970", Curved Not Notched, 66"x90° CO
56218670 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.970", 24"x90° CO
56219050 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.970", 66"x90°
56220380 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.990", Straight No Notch, Bevel Out, EZ-Coil ACW
56220190 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.990", Curved Not Notched, 66"x90°
56219430 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.990", Straight No Notch, 48"
56219620 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.990", 50"x90°
56219810 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.990", 66"x45°
56220000 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 0.990", 66"x90°
56220760 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", Straight No Notch, Bevel Out, EZ-Coil ACW
56221330 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", Curved, 66"x90°
56220570 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", Straight No Notch, 48"
56220950 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", 50"x90°
56221140 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1", 66"x90°
56221710 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.023", Straight No Notch, Bevel Out, EZ-Coil ACW
56221520 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.023", Straight No Notch, 48"
56222280 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.023", 37.5"x90°
56222090 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.023", 51"x90°
56221900 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.023", 66"x90°
56222470 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.025", 66"x90° CO
56222850 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.030", Straight No Notch, Bevel Out, EZ-Coil ACW SO
56223040 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.030", Straight No Notch, 48" CO
56222660 Bohler US 8/10 - 4PT, 10T, CF/US, T36, 1.030", Straight No Notch, Dispenser Coil
56290870 Bohler US 8/10 - 6PT, 8T, CF/US, 0.970", Straight No Notch, 48" CO
56291060 Bohler US 8/10 - 6PT, 8T, CF/US, 0.990", Straight No Notch, 48"
56291250 Bohler US 8/10 - 6PT, 8T, CF/US, 1", Straight No Notch, 36"
56291630 Bohler US 8/10 - 6PT, 8T, CF/US, 1.015", Straight No Notch, 48" CO
56291820 Bohler US 8/10 - 6PT, 8T, CF/US, 1.025", 48"
56292010 Bohler US 8/10 - 6PT, 8T, CF/US, 1.030", Straight No Notch, 48"
56292200 Bohler US 8/10 - 6PT, 8T, CF/US, 1.050", Straight No Notch, 48" CO
